Product Details
Place of Origin: Jiangsu, China
Brand Name: Lianti
Certification: ISO9001
Model Number: 3582(6:1)
Payment & Shipping Terms
Minimum Order Quantity: 1.0 Barrels
Packaging Details: Component A: 12KG, plastic drum Component B: 5KG, plastic drum. Also can be customized.
CAS No.: |
63148-60-7 |
Other Names: |
Silicone Sealant |
EINECS No.: |
Unspecified |
Place Of Origin: |
Jiangsu, China |
Classification: |
Other Adhesives |
Main Raw Material: |
Silicone |
Usage: |
Solar Module, Packing, Solar Module |
Brand Name: |
Lianti |
Model Number: |
3582(6:1) |
Type: |
Two Component |
Application: |
Solar Module |
Certificate: |
ISO9001 |
Appearance: |
Paste |
Color: |
White/Black/Gray |
Quality: |
Guarantee |
Viscosity: |
Low Viscosity |
Feature: |
Excellent Thermal Conductivity |
Packing: |
12KG/5KG |
Shelf Life: |
1 Year |
CAS No.: |
63148-60-7 |
Other Names: |
Silicone Sealant |
EINECS No.: |
Unspecified |
Place Of Origin: |
Jiangsu, China |
Classification: |
Other Adhesives |
Main Raw Material: |
Silicone |
Usage: |
Solar Module, Packing, Solar Module |
Brand Name: |
Lianti |
Model Number: |
3582(6:1) |
Type: |
Two Component |
Application: |
Solar Module |
Certificate: |
ISO9001 |
Appearance: |
Paste |
Color: |
White/Black/Gray |
Quality: |
Guarantee |
Viscosity: |
Low Viscosity |
Feature: |
Excellent Thermal Conductivity |
Packing: |
12KG/5KG |
Shelf Life: |
1 Year |
KDW-3582 is used on all kinds of components of pouring sealing and protection. It can be deeply cured, and with good liquidity, UV resistance, weather resistance, rain resistance and dirt resistance after mixed. And it can serve for a long time on outdoor products of fixation, waterproof, dustproof and anticreep.
1.Two components silicone pouring compound, additional type
2.Low viscosity, easy to process, strong maneuverability
3.Low shrinkage rate, no corrosion, no stress
4.Excellent high temperature electrical insulation, thermal conductivity and stability
5.Good waterproof and dampproof performance
6.Automotive electronics module
7.Power control module
8.Solar panels junction box LED screen
9.LED wall washer, LED module, etc.
|
Property |
Unused |
Used |
||
|
A |
B |
|||
|
Uncured |
Color |
White/Black/Gray |
Transparent |
White/Black/Gray |
|
Viscosity (mpa·s) |
15000~30000 |
50~150 |
10000~20000 |
|
|
Density (g/cm³) |
1.25~1.35 |
0.97 |
1.20~1.30 |
|
|
Allowable operating time (25℃, min) |
≥15 |
|||
|
Complete cured time (25℃,h) |
6-12 |
|||
|
cured |
Tensile strength (Mpa) |
≥1.0 |
||
|
Elongation (%) |
≥100 |
|||
|
Shore hardness (A) |
30~40 |
|||
|
Volume resistivity (Ω·cm) |
≥1 X 1014 |
|||
|
Dielectric strength (KV/mm) |
≥15 |
|||
|
Thermal stability (℃) |
-60~+200 |
|||
|
Linear shrinkage (%) |
≤0.5 |
|||
|
Thermal conductivity |
≥0.4 |
|||
|
Flame retardant rating |
UL94V-0 |
|||
PS:Operation time is tested based on 100g rubber.All data was measured by testing after 7 days curing under the condition of 25℃ and 55%RH.
1.Weighing component A and B according to the ratio of 6:1, stirring evenly after mixed, then inject it to components and module which needed to be potting protected. It would be better to injected along one side of the wall, which can reduce the generation of air bubbles.
2.Placing the sealed component, and it would discharge bubbles by itself, if possible, vacuumizing and defoaming the mixed rubber before potting sealing. Directly cured at room temperature, usually the rubber will have elasticity within 1-6 hours.
3.If needing quantitative sealing equipment, please contact our sales men or marketing department.
